Zooz Low Voltage XS Relay
Turn almost any electrical load under 3 A into a smart device with the Zooz Low Voltage XS Relay. It’s a great choice for automating garage doors, entry gates, gas fireplace, or any analog equipment under 3 A that accepts simple relay on/off control.
Key Features
Dry Contact Relay
Connect and control 0-240 V loads up to 3 A.
Low Voltage Power
This relay runs on a 9-40 V loads up to 3 A.
Dry Analog Input
Connect it to a wall switch for manual control or separate the “S” input from the output to monitor analog sensors, including leak sensors and open/close sensors (no Voltage, see diagram).
Z-Wave Long Range
Extend your wireless coverage up to 1300 ft if your hub supports Long Range.
Compact Design
Designed to fit in stacked switch boxes or shallow electrical boxes.
Multicolor LED Indicator
The built-in LED indicator flashes green or red to show you what’s happening to make troubleshooting easier.
Built-in Signal Repeater
Helps maintain a fast, reliable Z-Wave mesh network.
Onboard Button
The relay is equipped with a Z-Wave button that can be used to toggle your load on/off, pair with your hub, or factory reset the device when needed.
Auto Timers
Reliable on/off schedules that continue working even if your hub goes offline.
